More about J&D Manufacturing Barnstormer Basket Fans
Powerful, Low-Maintenance Air Circulation for Livestock and Industrial Spaces
The J&D Manufacturing Barnstormer Basket Fan is built for high-performance air recirculation in dairy, swine, and poultry barns, as well as industrial settings. Engineered with ease-of-maintenance in mind, the Barnstormer features a patented easy-open front guard, letting you clean and maintain your fan in minutes—no tools required.
Its tapered guard design creates a high-velocity air pattern, allowing you to space fans further apart without sacrificing performance. That means fewer fans in your barn and more money in your pocket.
The Barnstormer is the only fan on the market with a hinged open front guard, making it the fastest to clean and get back into operation. Say goodbye to downtime and hello to energy-efficient, high-output airflow.
Key Features:
- Patented hinged front guard drastically reduces cleaning and maintenance time
- Ships fully assembled for quick installation
- Includes hot-dip galvanized ceiling mount bracket
- Industry-leading air velocity for wide-area coverage
- Quiet, efficient operation
- Direct drive motors—no belts or bearings to service
- White powder-coated guards for easy cleaning and corrosion resistance
- Variable speed motors available on 20" and 24" single-phase models (requires separate speed control)
- High-efficiency, maintenance-free motors with sealed ball bearings
- UL and CUL recognized motors with a 2-year manufacturer warranty
- Automatic thermal overload protection extends motor life
- Compatible with misting and fogging systems
- OSHA compliant—must be mounted a minimum of 7 feet above the floor
Specifications:
QC Part # | Mfg Part # | Size | CFM | HP | Volts | Phase | RPM | Amps |
---|---|---|---|---|---|---|---|---|
12097 | VBS12 | 12" | 1,020 | 1/10 | 115/230 | 1 | 698 | 1.42 / 0.77 |
10361JD | VBS20 | 20" | 3,650 | 1/3 | 115/230 | 1 | 1,691 | 3.8 / 1.9 |
10362JD | VBS24 | 24" | 5,250 | 1/2 | 115/230 | 1 | 1,666 | 4.8 / 2.4 |
19497-VBS36A | VBS36A | 36" | 10,050 | 1/2 | 115/230 | 1 | 844 | 6.1 / 3.09 |
13440 | VBS243A | 24" | 5,470 | 1/2 | 230/640 | 3 | 1,710 | 1.8 / 0.9 |
19497-VBS36CF | VBS36CF | 36" | 10,000 | 1 | 230/640 | 3 | 846 | 2.6 / 1.3 |
