NSI TORK® 7-Day Digital Timer

The NSI TORK® 7-Day Digital Timer (model EWZ201C) is an Astronomic Timer that gives you a simple way to control outdoor lighting, motors, security or parking lot lights. The software allows for use of two independent SPST contacts or a single channel DPST setting and for the programming of up to 32 On/Off points for each day of the week.

Features/Advantages:

• 32 on/off set points per week, minimum 1-minute cycle
• Capable of different schedules for each day of the week
• Automatic daylight savings time and leap year
• Unit retains permanent schedule during power failure
• AM/PM Clock Format
• Super-capacitor maintains real-time clock for 100 hours in a power failure
• Manual override, either on or off to the next scheduled event or permanently
• Compatible with incandescent, compact fluorescent and LED bulbs
• Automatically detects voltages in the 120-277 range

Specifications:

• SPST
• 30 AMP
• 120-277 VAC
• 1 HP
• NEMA 3 Locking Enclosure
• Dimensions: 5.25" W x 8.5" T x 3.5" D
• Weight: 2 lbs.

Applications:

• Outdoor Signs Display
• Lighting Security
• System Heating & Air Conditioning
