EB75 Pressure Regulating Valve - 3/4"

The EB75 is a compact and economical iron-body pressure-reducing and regulating valve, ideal for applications where space is limited. Designed for non-potable water systems, this valve ensures reliable pressure control without a cartridge-based design.

Key Features:

• Built-in Back-Pass Check: Allows water to flow back through the regulator in cases of thermal expansion from hot water heating devices.*
• Fully Pressure-Balanced Piston: Reduces and regulates high inlet pressures up to 300 PSI down to a factory-set 45 PSI.
• Performance-Tested: Each valve undergoes rigorous testing before shipment to ensure quality and reliability.

Specifications:

• Size: 3/4"
• Max Pressure: 20 PSI
• Min Pressure: 0 PSI
• Pressure Range: 0 to 20 PSI
• Inlet & Outlet Type: FNPT (Threaded)
• Material: Iron
• Max Temperature: 180°F

*Note: Not recommended for potable water applications.
